MAONO CASTER E2 Gen2 Audio Mixer & Interface & Podcast Equipment
- Up to 11 customized sound pads to enhance your podcast aumosphere
- Widely compatible with most microphone in the market.including XLR condenser/dynamic microphones, 6.35MM dynamic microphones, and 3.5MM microphones.
- Equipped with 6 reverb modes, you can adjust the time and depth of reverb freely
- Specially designed for podcasting, live streaming, and content creation.
Pickup available at Mastex Corporation
Usually ready in 24 hours
MAONO CASTER E2 Gen2 Audio Mixer & Interface & Podcast Equipment
Mastex Corporation
Unit 12, 163-179 Forster Road
Mount Waverley VIC 3149
Australia
Choose options
Podcaster | Live Streaming
Maonocaster E2 Audio Mixer & Interface
- Up to 11 customized sound pads to enhance your podcast aumosphereⅡ.
- Widely compatible with most microphone in the market.including XLR condenser/dynamic microphones, 6.35MM dynamic microphones, and 3.5MM microphones.
- Equipped with 6 reverb modes, you can adjust the time and depth of reverb freely
- Specially designed for podcasting, live streaming, and content creation.
Mic Volume Adjustment
Each Mic, Soundpads, Monitor, Input, and Output Volume can be adjusted individually to enjoy your podcast.
Intelligent Noise Reduction
Reduces background noises, you will get clean, distortion-free audio with a natural, warm sound.
Widely Compatibility
Compatible with most analog microphones in the market, including XLR condenser/dynamic microphones, 6.35MM dynamic microphones, and 3.5MM microphones.
Clearer Sound Transmission
Separate USB C jack to connect your computer, keep away from static noise
Voice FX
Switch to dry mode to bypass all audio processing and record a pure microphone signal.
8 Hours Working Time
Up to 8H working time after fully charged can really satisfy your use in more scenrios.
WHAT OTHERS THINK OF PD200XS
My initial thought about this microphone feels pretty nice, the shock mount is plastic and the actual mic feels like a metal material, I love the sleek look now, I find to be useful about this mic is that I like this mic is that it has the option to plug in through an xlr cable, I think it’s great quality, especially for the price point.
Katie Münch | 5.94K FOLLOWERS
PD200XS is a microphone that is easy to use because as I mentioned, I’m not somebody who is invested or specialized in microphones, for me, it sounds good straight out of the gate without any processing. It already sounds terrific. I do recommend this microphone to do whatever you want like podcasting or recording.
Gary Jahman | 6.73K FOLLOWERS
How to Use the Maonocaster AME2
The Maonocaster AME2 podcast equipment bundle is specially designed with 3-level microphone gain adjustment and 48V phantom power for the best performance of more microphones. We kindly suggest that you read the following notes before use.
1. Please confirm your microphone type and sensitivity first before buying
If you connect to your own microphone, please refer to the user manual of the microphone to confirm the microphone type and sensitivity.
2. Please confirm if your microphone needs to turn on the 48V phantom power
XLR-connected condenser mics require phantom power, dynamic mics do not.
3. Please adjust the 'MIC1 SETTING' on the side of the audio interface to the correct position.
40dB: condenser mic sensitivity higher than -40dB, like MAONO microphone PM320/PM500/AT2020
50dB: dynamic mic sensitivity between -50dB and -55dB, like Samson Q2U/HD300T
60dB: dynamic mic sensitivity between -55dB and -60dB, like Well-known models SM7B/SM58/MV7
Note (Please read carefully before placing the order):
1. Please be well learned that it is not recommended to directly connect AME2 and other Maono audio mixers to iPhones via OTG adaptor cable, as the sound quality experience may not be as good as when connected to Android. (Sound will be good if connect with Andriod) The main reason is that some system restrictions on Apple mobile phones will cause incompatibility.
2. USB microphones are not supported. You can use the product with MAONO PM320, PM500, and HD300, It also works well with microphones of other brands, including Shure SM7B, Shure SM58, Rode podmic, Samson Q2U, etc.
If you need any help with the AME2, welcome to leave us the message to angela@maono.com
Co-hosted Podcasting Solution
Solo Podcasting Solution
PACKAGE LIST
1* E2 Audio Mixer , 1* USB A-C charging cable, 2* 3.5mm TRS audio cable, 1* user manual.
We provide a 12-Month warranty. For a better user experience, please download more instructions below and read the user manual before setting up.
SPECIFICATIONS
| Data Transmission | |
|---|---|
| Frequency Response | 20Hz-20kHz |
| THD | THD<0.05% 1kHz |
| Headset Output Power | 20mW, 32Ω (1kHz, THD+N=1%) |
| Sample Rate | 48kHz /16bit |
| Wireless Connection | Bluetooth 4.2 |
| Battery Type | Li-Polymer |
| Battery Capacity | 2000mAh |
| Charge Parameter | 5V/1A |
| Charge Time | Appr. 3h |
| Battery Life | Appr. 8h (Highest keypads brightness) |
| Dimension | L24.5*W15.7*H5.5CM(button included) |
